Nickel Titanium Alloys

nickel titanium alloys is a binary alloy composed of nickel and titanium, both elements having approximately equal atomic percentages (Nitinol 55 and Nitinol 60 are very common). Due to variations in temperature and mechanical stress, nickel-titanium alloys have two different crystal structures, called austenite and martensite.
  • As customers' demands

  • Hongguan


What is nickel titanium alloys?

nickel titanium alloys is a nickel-titanium alloy with super elasticity and shape memory properties. Shape memory refers to the ability of a NiTi alloy to deform at a certain temperature and then recover its original, unshaped shape when heated above its transformation temperature. Superelasticity occurs in a narrow range of temperatures just above its transformation temperature; in this case, no heating is required to restore the unshaped shape, and the material exhibits tremendous elasticity, about 10-30 times that of ordinary metals.

Nickel-Titanium Alloy Product Description

Products Sheet/Plate/Coil/Pipe/Tube/Strip/Wire/Bar/Rod
Type Hot rolled Cold rolled
Grade ASTM Pure Ti: Gr.1 Gr.2 Gr.3 Gr.4 Ti Alloy: Gr.5 Gr.7  Gr.9 Gr.11JIS Pur Ti: Class 1 Class 2 Class 3 Class 4;Ti Alloy: Class 60  Class 12 Class 61 Class 11 Class 60 EGB Pure Ti:TA1 TA2 TA3 TA4;Ti Alloy: TC4  TA9 TC2 TC4 ELI
Surface finish 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered,  embossed, hair line, sand blast, etching, brush, etc
Standard ASTM A240, GB/T3280-2007, JIS4304-2005, ASTM A167,  EN10088-2-2005, etc
Thickness 0.01mm to 100mm
Package Standard export package, suit for all kinds of  transport, or as required, etc

nickel titanium alloys products


TA1 Titanium


TA2 Titanium


TA3 Titanium


TA4 Titanium


TC4 Titanium


TC2 Titanium


TC9 Titanium


Gr.1 Titanium

nickel titanium alloys mechanical properties

GB JIS Element Content(wt%) Mechanical Properties
N,max C,max H,max Fe,max O,max Others Strength Of Extension Ductility
Mpa,min %,min
Pure Titanium Gr.1 TA1 Class1 0.03 0.08 0.015 0.2 0.18
240 24
Gr.2 TA2 Class2 0.03 0.08 0.015 0.3 0.25 345 20
Gr.3 TA3 Class3 0.05 0.08 0.015 0.3 0.35 450 18
Gr.4 TA4 Class4 0.05 0.08 0.015 0.5 0.4 550 15
Titanium Alloy Gr.5 TC4 Class60 0.05 0.08 0.015 0.4 0.2 AI:5.5-6.75 895 10
Ti-6A1-4V V:3.5-4.5
Gr.7 TA9 Class12 0.03 0.08 0.015 0.3 0.25 Pd:0.12-0.25 345 20
Gr.9 TC2 Class61 0.03 0.08 0.015 0.25 0.15 AI:2.5-3.5 620 15
Gr.11 TA9-1 Class11 0.03 0.08 0.015 0.2 0.18 Pd:0.12-0.25 240 24
Gr.23 TC4 ELI Class60E 0.03 0.08 0.0125 0.25 0.13 AI:5.5-6.5 828 10

Our Service/Why Choose Us

(1)Fast delivery time, good quality and reasonable price

(2)We can process different finished products according to your requirements

(3)High production volume will shorten your waiting time

(4)Accept the buyer's specification

(5)Experienced R&D department

For more details about our products, please contact our sales for more information. Thank you for your visit.
